High temperature test chamber GJB360.8-1987 standard test conditions

The test conditions specified in the high temperature test chamber GJB360.8-1987 are as follows:

The test temperature is selected from the table below.

Temperature and tolerance °C

Temperature and tolerance °C

70±2

150±3

85±2

200±5

100±2

350, tolerance according to regulations

125±3

600, tolerance according to regulations

Note: When the resistor is tested in a static air environment condition, the maximum temperature tolerance is ±5 °C (still air is defined as: no air circulation except the air circulation formed by the heat of the working element)

The test time is selected from the following table:

Test level

Test time h

Test level

Test time h

A

96

F

3,000

B

250

G

5,000

C

500

H

10,000

D

1,000

I

30,000

E

2,000

J

50,000

Working conditions specified in the high temperature test chamber GJB360.8-1987: During the test, the test voltage, work cycle, load and other working conditions imposed on the test sample are specified by relevant standards.
